Note the LushOne kits are no longer available - these pages are kept for reference and interest. You can find the schematics and source code in these documents, but the PCB designs are not currently public.

Use the LushOne Contour

Quick Reference Guide

Contour Quick ReferenceThe Contour Quick Reference Guide describes the functions of all the parts of the LushOne Contour and suggests some common applications.

For a more tutorial-based approach please use the files and videos below.

201 Contour Module – Intro, Using ADSR Envelope

LushOne 201 (Notes in PDF)

Skip to about 8:20 in the video if you just want to hear the sound demo.

202 Contour Module - Voltage Controlled Amplifier (VCA)

LushOne 202 (Notes in PDF)

Go to 06:40 for sound samples with VCA connected to ADSR to control dynamics.

Go to 13:44 for sound samples with VCA as a control voltage multiplier.

203 Contour Module - Ring Modulator (RM)

LushOne 203 (Notes in PDF)
